General & Dimensions

Form Factor: Full Tower

Dimensions (DWH): 522 x 230 x 522 mm

Materials: Steel, Plastic, and Dual 4mm Tempered Glass Panels

Net Weight: 12.55 Kg

Side Panel: 4mm Tempered Glass (both sides)

Cooling & Airflow
Mesh Design: The front panel features a fine, 1.2mm mesh for excellent airflow.

Pre-installed Fans: The case comes with four pre-installed “Storm T3″ PWM fans, which are 30mm thick for improved airflow and pressure.

Front: 3 x 140mm fans

Rear: 1 x 120mm fan

Fan Support (Total):

Front: 3 x 120mm / 3 x 140mm

Top: 3 x 120mm / 3 x 140mm

PSU Shroud: 3 x 120mm

Rear: 1 x 120mm

Radiator Support:

Front: Up to 420mm

Top: Up to 360mm

Rear: Up to 120mm

Dust Filters: It includes magnetic and clip-on dust filters on the front, top, and bottom for easy cleaning.

Component Compatibility & Clearances
Motherboard Support: E-ATX, ATX, Micro-ATX, ITX

Max GPU Length: ≤ 400mm

Max CPU Cooler Height: ≤ 175mm

Max PSU Length:

With HDD cage: ≤ 245mm

Without HDD cage: ≤ 440mm

Expansion Slots: 8 (bridgeless design)

Drive Bays:

3.5″/2.5″: 2

Dedicated 2.5”: 3

Front I/O & Controls
Temperature Display: A key feature is the integrated display on the front I/O that can show real-time CPU or GPU temperatures, which can be toggled with a switch. This requires the Antec iUnity software to function.

Ports:

USB 3.0: 2x

USB Type-C: 1x (10Gbps)

Headphone/Mic Combo Jack

Power & Reset Buttons

Other Features

Cable Management: The case provides 30mm of cable management space with integrated channels and multiple Velcro straps to help keep your build clean.

Removable Top Panel: The top cooling bracket is removable, which simplifies the installation of fans and radiators.oling setups.
