General & Dimensions
Form Factor: Mid Tower

Dimensions (DWH): 470 x 210 x 485mm

Materials: Steel, Plastic, and Glass

Side Panel: 4mm Tempered Glass (270° full-view design)

Net Weight: 7.56 kg

Cooling & Airflow
Design: Features a “honeycomb” mesh design on the top, bottom, and right side for smooth airflow.

Pre-installed Fans: Comes with four pre-installed PWM ARGB fans.

Side: 3 x 120mm PWM ARGB reverse fans

Rear: 1 x 120mm PWM ARGB fan

Fan Support (Total):

Top: 3 x 120mm / 2 x 140mm

Side: 3 x 120mm

Bottom: 1 x 120mm (requires removing the HDD cage)

Rear: 1 x 120mm

Radiator Support:

Top: Up to 360mm

Side: Up to 240mm

Rear: Up to 120mm

Dust Filters: Includes removable dust filters on the top, right side, and bottom for easy maintenance.

Component Compatibility & Clearances
Motherboard Support: ATX, Micro-ATX, ITX

Max GPU Length: ≤ 415mm

Max CPU Cooler Height: ≤ 160mm

Max PSU Length: ≤ 195mm (including cables)

Expansion Slots: 7

Drive Bays:

3.5″ / 2.5″: 1/1

Dedicated 2.5″: 3

Front I/O & Controls
Power Button

LED Control Button

USB 3.0: 1x

USB Type-C: 1x (3.2 Gen 2 for 10Gbps high-speed transfer)

Headphone/Mic Combo Jack

Other Features
Tool-Free Design: The case is designed with drop-proof bolts and fixing slots for the glass panels, making component installation and cleaning easier.

Cable Management: Provides 23mm of space behind the motherboard tray for tidy cable routing.

ARGB Control: The pre-installed fans are connected to a built-in fan controller, allowing you to manage both fan speed and lighting effects.
