SPECIFICATIONS
main spec
Dimensions 485 x 241 x 504mm(DWH)
Form Factor Mid Tower
Materials Steel + Plastic + Glass
Mainboard Support E-ATX (≤ 272mm), ATX, M-ATX, ITX
Front Access & Controls Power, LED Control Button, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack
Side Panel 4mm Tempered Glass
Drive Bays
Expansion Slots 7
3.5″ / 2.5″ Normal M/B: 3/3
M-ATX Back Connect: 3/3
ATX Back Connect: 2/2
2.5″ Normal M/B: 2
M-ATX Back Connect: 1
ATX Back Connect: 1
Fan Support
Top 3 x 120 / 2 x 140mm
Side 3 x 120mm
Power Supply Shroud 3 x 120mm
Rear 1 x 120 / 1 x 140mm
Included Fan(s) 3 x 120mm ARGB PWM reverse fans on right side + 1 x 140mm ARGB PWM fan in rear
Radiator Support
Top 120 / 140 / 240 / 280 / 360mm
Side 120 / 240 / 360mm
Rear 120 / 140mm
Clearance
Max GPU Length ≤ 450mm
(When overall AIO thickness > 52mm, the length of the graphics card is limited to 280mm.)
Max CPU Cooler Height ≤ 180mm
Max PSU Length (Include cable) ≤ 210mm
Miscellaneous
Dust Filter Front / Left Side / Bottom
Net Weight 11.7Kg
Gross Weight 14.2Kg
